China Solid Conveying System manufacturer

Solid Handling Compact 25kg/m³ Bag Dust Collector

Product Details:
Place of Origin: China
Brand Name: Hanrui
Certification: CE
Model Number: HFT15AP
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: plywood
Delivery Time: 6-8 weeks
Payment Terms: T/T, Western Union
Supply Ability: 1000 sets/year

Detail Information

Filter Efficiency: 99.99% Max Temperature: 204 ℃
Flaw Resistance: 25kg/m³ Other Advantage: Washable Resistance Acid& Alkali
Material: SS304, SS316, SS316L , Q235 Certification: CE Certification
Normal Temperature: 130℃ Service Life: More Than 10 Years
Highlight:

0.4MPa bag filter dust collector

,

99.99% Bag Dust Collector

,

25kg/m³ Bag Dust Collector

Product Description

compacted structure and easy installation dust filter for solid handling



Hanrui Puzer is professional as one of the leading dust collector manufacturers and suppliers in China. Equipped with advanced equipment and experienced staff, we now have high quality products for sale. Should you have any interest in it, please feel free buy dust  collectors at best price with us. We will offer you the greatest after-sales service and fast delivery.



Product description

Dust collector is designed to seperate superfine particle or even sub-micron dust from process gas with micropore fiber material. It is widely applied to chemical industries, food,medicine, electric power, metallurgy and concrete industry. Dust filter can be divided into pneumatic conveying filter and silo filter according to its use. It can be also divided into bag filter and cartridge filter according to structure.Filter material is made of fiber, common felt, felt with Tex, polyester, Nomex, polymer cloth, Teflon, terylene, Plypropylene...It is widely used to cement, power plant, casting plant, electric power, metallurgy and concrete industry. Dust filter can be divided into pneumatic conveying filter and silo filter according to its use.



Product advantages

1. High filter efficiency of bag dust collector

2. Integrated construction design and easy installation.

3. Bag collector has compacted structure to reduce the filter collector covering area and realize superfine dust filtration.

4. The bags are resistant to acid and alkali, to moisture, non-bond on filter surface.

5. Impulse back cleaning, mechanical shake cleaning and acoustic wave cleaning can be used in dust collector. The impulse back cleaning filter components: impulse controller, solenoid valve, nozzle, differential pressure meter, safeguard and sight glass etc.

Model Parameters HFD-32 HFD-48 HFD-64 HFD-80 HFD-96 HFD-112
Air Volume(m3·h) 1500-2100 2100-3200 2900-4300 4000-6000 5200-7000 6000-9000
Filter Area(m2) 24 36 48 60 72 84
Filter Wind Speed(m/min) 1.0—1.5 1.0—1.5 1.0—1.5 1.1—1.7 1.2—1.7 1.2—1.8
Material can be selected can be selected can be selected can be selected can be selected can be selected
Entrance Gas Temperature(℃) ≤120
Equipment Resistance(Pa) ≤1200
Soot Cleaning With Air Pressure(MPa) 0.4~0.6
No.of Pulse Valve 4 6 8 10 12 14
Blower Motor Power(KW) 1.5 3 3 5.5 5.5 7.5



Product application

Bag filter is widely used to chemical industries, food, medicine, electric power, metallurgy and concrete industry. Dust filter can be divided into pneumatic conveying filter and silo filter according to its use.



Shipping

  1. We ship out your order by sea or air according to customer‘s request.
  2. We will try to ship out your order within 1 week after receiving your payment.
  3. We will inform you with the tracking number once your order has been sent out.
  4. We accept T/T bank transfer and other ways.



Why Choose Us?

  1. We provide OEM/ODM products and services according to international standard and customer requirements. We accept customer label / logo.
  2. We have R&D abilities to enhance product performance and quality according to customer’s demands.
