China Solid Conveying System manufacturer

380V SS316L Automatic Slitter With Tubular Chain Conveyor

Product Details:
Place of Origin: Shanghai,China
Brand Name: Hanrui Puzer
Certification: CE, ISO9001
Model Number: HGA50-1200
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: Stretch film/ply wood
Delivery Time: 5-8 weeks
Payment Terms: T/T, Western Union
Supply Ability: 400 sets /year

Detail Information

Material: SS304, SS316L, SS316, WCB Etc. Accessories: Belt Conveyor /rotary Valve Etc.
Capacity: 30-1800bags/H Weight/bag: >1000kg
Appliable Field: Chemical/pharmacy/food Etc. Dust Filter: Can Be Equiped
Conveying Type: Mechanical/pneumatic Working Voltage: 380V, 3P, 50HZ
High Light:

380V Automatic Bag Slitter

,

50HZ Automatic Slitter

,

SS316L Automatic Slitter

Product Description

Automatic ton bag slitter connecting with hopper and tubular chain conveyor



The machine is mainly suitable for toxic, flammable and strong corrosion, high dust and conditions that unsuitable for manual .It is widely used in petroleum, chemical, chemical fiber, dyes, medicine, food, electronics, paper, building materials, power , environmental protection, metallurgy and other production areas, it can automatically unpack any material bags (such as plastics , mixing agents, sewage treatment clarifiers, cement and other dry powders, granular materials, powder mixtures, flakes etc.)

Model HGA1-120BP
Max. slitting capacity 1200bag/hr
Max single package weight 50KG/bag
Accessories Dust collector/rotary valve/screw conveyor
Max. unwinding width Depending on your condition
Total power Depends on your working condition
Material SS304, SS316, Q235 etc.
Package Stretch film /plywood/ wooden pallet

380V SS316L Automatic Slitter With Tubular Chain Conveyor 0

Main parameters



◆Unpacking capacity: 2000 bags/ hour (maximum).

◆Wide range of unpacking: 0.1kg ~ 70kg/ bags

◆Packing bags’ material: kraft paper, plastic film, woven bag, jute bag, compound bag etc.

◆Material loss rate: 1/1000 ~ 1/10000

◆Dust emission concentration: 1mg/m3~30mg/m3

◆Dust collection efficiency: 99.9% ~99.999%

◆Minimum dust particle size: 0.1um



•Main type(Classified by main structure)
•Horizontal blade type
•Vertical blade type
•Spiral blade type
•High-speed unpacking type
•Vacuum unpacking type




FRQ questions:

1. Can we choose the material of the equipment ?

Yes, for material , you can choose SS304, SS316, SS316L , Q235 or other .

2. What should we supply you when we need to select a proper size ?

You need to let us know your detailed site condition, such as working temperature, working pressure etc. We need your material information as well , such as material name , bulk density, particle size, material flowablity etc.

3. What is other information we need to supply before get a quotation?

We need you give us the brand of the motor and reducer, whether is it explosition-proof or not ?By the way, we will send you a data sheet to collect information we need .

4. Can we choose the brand of the parts ?

Yes , you can select parts brand according to your own requirement.
