SS316 Slide Gate Valve

Product Details:
Place of Origin: China
Brand Name: Hanrui
Certification: CE
Model Number: HHA150
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiable
Packaging Details: plywood
Delivery Time: 4-6 weeks
Payment Terms: T/T, Western Union
Supply Ability: 3000SETS/YEAR

Detail Information

Material: SS304, SS316, Q235 Main Size: DN50-DN1000
Working Temperature: -20℃~500℃ Connection Methord: Wafer/flange Type
Packaging Type: Stretch Film /plywood Etc. Working Pressure: ATM-0.35MPa
Drive Type: Manual/electric/pneumatic Surface Polish: Can Reach 400#
High Light:

150LB slide valves

,

0.1MPA Slide Gate Valve

,

SS316 Slide Gate Valve

Product Description

High automation level slide gate valves with closed structure

Hanrui Puzer is professional as one of the leading slide gate valve manufacturers and suppliers in China. Equipped with advanced equipment and experienced staff, we now have high quality products for sale. Should you have any interest in it, please feel free buy slide gate valve at best price with us. We will offer you the greatest after-sales service and fast delivery.

Product details

Working pressure of slide gate valve: ATM/0.1MPA~0.35MPA

Working temperature of slide gate valve: -20℃~500℃

Main size: DN100-1000

Main material: SS304, SS304L, SS316, SS316L, WCB and etc.

Driving model: manual, pneumatic or electrical

Connection model: wafer type and flange type

Flange Connection Rating: ANSI B16.5 150LB, GB, HG, SH or designated by client



Mian Technical Data Sheet

working pressure  ATM/LP--ATM/0.1MPA     MP--0.35MPa
Working temperature -20℃-200℃,≤500℃
Main size  DN50-DN1000MM(2''-40'')
Main materials SS304, SS304L,SS316, SS316L, WCB etc.
Connection Methord Wafer type / Flange type
Applicable medium Solid materials(Powder, particles, Powders/particles mixtures etc. )



Product application

This slide gate valve is mainly used in opening and closing pipeline in the solid material conveying system. Its fully closed structure is applicable for outdoor condition. And generally this knife gate valve is used at the bottom of silos, hoppers or other related equipment.



FRQ questions:

1. Can we choose the material of the slide gate valve ?

Yes, for material , you can choose SS304, SS316, SS316L , Q235 or other .

2. What should we supply you when we need to select a proper size ?

You need to let us know your detailed site condition, such as working temperature, working pressure etc. We need your material information as well , such as material name , bulk density, particle size, material flowablity etc.

3. What is other information we need to supply before get a quotation?

We need you give us the brand of the motor and reducer, whether is it explosition-proof or not ?By the way, we will send you a data sheet to collect information we need .

4. Can we choose the brand of the cylinder?

Yes , you can select cylinder brand according to your own requirement.
