China Solid Conveying System manufacturer

30m/s Pneumatic Conveying Pipe

Product Details:
Place of Origin: China
Brand Name: hanrui
Certification: CE
Model Number: DN125-
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: ply wood/stretch film
Delivery Time: 4-8 weeks
Payment Terms: T/T, Western Union
Supply Ability: 1000 sets /year

Detail Information

Material: SS304, SS316, Q235 Etc. Type: Dilute/dense Phase Conveying
Voltage: 380V, 400V, 690V Etc. Capacity: 50-100000kg/h
Conveying Distance: 1-800m Main Size: DN125-400
Conveying Direction: Vertical/horizontal Conveying Speed: 15-30m/s
High Light:

304L Pneumatic conveying pipe

,

30m/s Pneumatic conveying pipe

,

800m pneumatic handling system

Product Description

Pneumatic conveying pipe can meet hygiene requirement and for material transporting

Hanrui Puzer is professional as one of the leading slide gate valve manufacturers and suppliers in China. Equipped with advanced equipment and experienced staff, we now have high quality products for sale. Should you have any interest in it, please feel free buy slide gate valve at best price with us. We will offer you the greatest after-sales service and fast delivery.



We provide STATE-OF-THE-ART Pneumatic Conveying System for different solids (powder/pellets).

We offer customized solution for solid transfer, providing clean, leak-proof, safe atmosphere in material handling plant.

We offer broadly dilute phase and dense conveying system.



Frame Material Carbon steel, 304,304L / 316L stainless steel
Power & Output 3 phase 380V 50Hz
Accessories screw conveyor, diverter valve , rotary valve etc.
Working condition pneumatic/gravity
1. Accommodate Your needs.
Flexible modular design makes this discharger most suitable for a wide range of applications to best accommodate your needs.
2. Cost efficiency:
Dustless operation helps you to save extra cleaning cost. Incorporated dust collector to help you save cost on a separate dust-collection-device.
3. Space Efficiency:
Understanding the requirement of your project on environment and space, our professional R & D team will design the most appropriate system to suit your needs.
4. Optional Component:
Flow-control valve >Dust collector >Exit conveyor>Dumper>Store hopper>Weighing system
Dilute Phase Pneumatic Conveying System (Lean Phase)

  • This system works on solid to air ratio.
  • System has low air pressure, high air volume.
  • System works with high velocity solid transfer.
  • System work with pressure conveying i.e. air blow or vacuum conveying viz. air suck.
  • Use of wide variety of solid system commonly used for, Non-Abrasive material, Economical up to 200 meter conveying
  • System mainly comprises of Positive Displacement Blower (pressure < 2 bar), Rotary Feeder and Product Separator.


Why Choose Us?

  1. We provide OEM/ODM products and services according to international standard and customer requirements. We accept customer label / logo.
  2. We have R&D abilities to enhance product performance and quality according to customer’s demands.
  3. We have nearly 20 years of experience in bulk material area.
  4. We have many certificates to guarantee and ensure product quality and safety, including ISO 9001: CE, ISO14001 etc.
  5. Any questions will be replied within 24 hours.

Necessary information when order:

1. Location: indoor or outdoor

2. Kindly provide the installment position and the conveying distance

3. Capacity(KG/H), and remark the ration conveying or variable conveying

4. Product characteristic: name, size, bulk density, temperature, stickness and other special characteristics

5. Flange standard and flange dimension

6. Please provide reducer motor working voltage, IP grade Ex-proof grade and other automation control requirements
