China Solid Conveying System manufacturer

CE Stainless Steel DN125 Pneumatic Conveying Pipe

Product Details:
Place of Origin: China
Brand Name: hanrui
Certification: CE
Model Number: DN125-
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: ply wood/stretch film
Delivery Time: 4-8 weeks
Payment Terms: T/T, Western Union
Supply Ability: 1000 sets /year

Detail Information

Material: SS304, SS316, Q235 Conveying Type: Dilute/dense Phase Conveying
Working Voltage: 380V, 400V, 690V Etc. Color Paint: Can Be Selected
Max Length: 800-1200M Main Size: DN125-400
PLC Control: Can Be Selected Package Type: Stretch Film/plywood
High Light:

400V Pneumatic Conveying System

,

800M Pneumatic Conveying Pipe

,

DN125 Pneumatic Conveying Pipe

Product Description

Pneumatic conveying pipe with related powder conveying equipments



Hanrui Puzer is a high-tech enterprise built in 2002 , we are a professional supplier for providing solid bulk material handling solutions, integrated with designing , manufacturing sales and EPC service . Our mission is dedicated to provide excellent solutions and services of handling solid bulk material in order to consistently create maximum value for customers.

We provide STATE-OF-THE-ART Pneumatic Conveying System for different solids (powder/pellets).

We offer customized solution for solid transfer, providing clean, leak-proof, safe atmosphere in material handling plant.

We offer broadly dilute phase and dense conveying system.



Components and principle:

1. The system is combined with feed hopper, rotary valve or venturi devices, pipelines and receiving hopper and filter, the air supply is roots blower or centrifugal fan.

2. Material is poured into the feed hopper , then discharged to pipe through the rotary valve or venturi, the mixture of air and material moves from the pipe to receiving hopper resorting compressed air, the air is separated from the mixture on the top of receiving hopper and released.

3. The material in the pipelines moves at a suspended state.





specifications conveying speed conveying distance operation pressure SLR Pipe material
description 15-30M/S Max:800m Max:0.1MPa 3-15KG/KG SS304, Q235 etc.



Why Choose Us?

  1. We provide OEM/ODM products and services according to international standard and customer requirements. We accept customer label / logo.
  2. We have R&D abilities to enhance product performance and quality according to customer’s demands.
  3. We have nearly 20 years of experience in bulk material area.
  4. We have many certificates to guarantee and ensure product quality and safety, including ISO 9001: CE, ISO14001 etc.
  5. Any questions will be replied within 24 hours.

About us


Hanrui PuZer Bulk Handling Technology (Shanghai) Co., Ltd. (originally called Shanghai Hanrui Machine Engineering Co., Ltd.), founded in 2002, is a scientific and technological enterprise integrating with design, fabrication, sales, installation, debugging and services. The assets of Hanrui company is over 80 million yuan. Now we have two plants in Songjiang District and Jinshan District. And we have the representative offices in Beijing, Nanjing, Chengdu and Toronto.



The main services of Hanrui company are in the trade of petroleum and chemical, chemical fiber, plastic resin, metallurgy, pharmacy, food, environmental protection and coal gasification industries. In the past thirteen years, our company has been committed to provide competitive solid bulk material handling system solutions and services, mainly includes the engineering general contracting of solid bulk material handling system and its related equipment manufacturing.


FRQ questions


1. Can we choose the material of the equipment ?

Yes, for material , you can choose SS304, SS316, SS316L , Q235 or other .

2. What should we supply you when we need to select a proper size ?

You need to let us know your detailed site condition, such as working temperature, working pressure etc. We need your material information as well , such as material name , bulk density, particle size, material flowablity etc.

3. What is other information we need to supply before get a quotation?

We need you give us the brand of the motor and reducer, whether is it explosition-proof or not ?By the way, we will send you a data sheet to collect information we need .

4. Can we choose the brand of the motor & reducer ?

Yes , you can select motor and reducer brand according to your own requirement.



FRQ questions:

1. Can we choose the material of the equipment?

Yes, for material , you can choose SS304, SS316, SS316L , Q235 or other .

2. What should we supply you when we need to select a proper size ?

You need to let us know your detailed site condition, such as working temperature, working pressure etc. We need your material information as well , such as material name , bulk density, particle size, material flowablity etc.

3. What is other information we need to supply before get a quotation?

We need you give us the brand of the motor and reducer, whether is it explosition-proof or not ?By the way, we will send you a data sheet to collect information we need .

4. Can we choose the brand of the motor?

Yes , you can select cylinder brand according to your own requirement.
