China Solid Conveying System manufacturer

No Pollution SS304 2500KG Jumbo Bag Unloading System

Product Details:
Place of Origin: Shanghai,China
Brand Name: Hanrui Puzer
Certification: CE, ISO9001
Model Number: HGA50-1200
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: Stretch film/ply wood
Delivery Time: 5-8 weeks
Payment Terms: T/T, Western Union
Supply Ability: 400 sets /year

Detail Information

Material: SS304, SS316L, SS316, WCB Etc. Accessories: Screw Conveyor /dust Collector/Tubular Chain Conveyor
Capacity: 30-1800bags/H Weight/bag: >1000kg
Appliable Field: Chemical/pharmacy/food Etc. Residual: Small Amount
Sealing: Good Sealing Pollution: No Pollution
High Light:

SS304 bag unloader

,

2500KG bag unloading system

,

jumbo bag unloading system

Product Description

Jumbo Bag Unloading system / Ton bag discharging machine / Automatic Bag Slitter



Ton bag discharging machine is mainly applied to the powder material of 500KG-2500KG bag's unloading. It is widely used in industries of chemicals, plastics, sewage treatment, infrastructure and other industries.
Ton- bag breaker charter not only protect the production environment effectively, reduce the intensity of workers, improve production efficiency, but also solve the problems of the material is easy block due to moisture absorption and the problem of material is difficult to be discharged.

After unpacking the bag, the material can be conveyed to proper position by the chains conveyor, screw conveyors, pneumatic conveying systems or other specialized conveying equipment.

Features:

1. Simple open- bag structure and easy for operation
2. Tapping device can ensure the material smoothly feed into the next process from the sack
3. Crusher breaks the block during splitting the bag to ensure the next processing work smoothly.
4. Fully automated operation that increase productivity and reduce labor intensity;
5. Sealed split bag that prevent dust emissions, no heat generation, improve the working environment, reduce production costs;
6. Cutting the bag, beating, crushing, magnetic separation integrated design makes structure compact and operation convenient .
7. After unpacking the bag, the material can be conveyed to proper position by the chains conveyor, screw conveyors, pneumatic conveying systems or other specialized conveying equipment.



Bulk Bag Unloader
Technical parameters Model HGC1AP
Unloading Speed Depends on your material
Air consumption 4m³/hr
accessories dust collector, hoist etc.
Frame Material Carbon steel, 304,304L / 316L stainless steel
Power & Output 3 phase 380V 50Hz,2.0KW
Total weight Depends on your material
Machine Dimension depends on working condition





Function and characteristics

◆Reduce the amount of workers as well as the labor intensity.

◆No dust leakage and improve the operating environment.

◆Never pollutes the material and low material loss.

◆Can satisfy the food level, explosion- proof, toxic materials and other special conditions.

◆Automatic and intelligent operation: system automatic monitoring and real time display of running state, automatic counting and measurement, interlock, alarm signal output and feedback can interlock with the customer s central DSC control system.

◆Other functions like automatic de-palltizing from stacking pallet, unpacking, automatic waste bag collecting and packing, pallet automatic recycling, material handling, dust collecting, weighing and dosing can realize the automatic and intelligent production.



Typical engineering application

◆Polymer (polypropylene, polyethylene, polystyrene, polyvinyl chloride, polycarbonate, polyester, nylon, pom, ABS, etc.).

◆Food and pharmaceutical raw materials (glucose, white granulated sugar, protein powder, milk powder, sorbic acid,alcohol, monosodium glutamate, salt, coffee, maltodextrin, yeast, wheat, rice, soybean, pepper powder, citric acid,gluten flour, starch, etc.).

◆Chemical raw materials (urea, ammonium bicarbonate, ammonium nitrate, sodium nitrate, lithium carbonate,chloroacetic acid, potassium chloride, sodium hydroxide, industrial salt, etc.).

◆Dye, coating, paint, ceramic ( titanium dioxide, gypsum, calcium carbonate, barium sulfate, ferrotitanium powder,coarse whiting, talcum powder, kaolin, etc.).

◆Additives, water clarifying agent, additives, detergent (calcium carbonate, carbon, activated carbon, washing powder,bleaching powder, etc.).

◆Building materials: cement, quartz sand, lime,rubber owder, etc.

◆Other industries: other bulk bags which are suitable for automatic unpacking powder (powder, particles, flake, etc.).



Why choose us

1. Hanrui can supply you better solutions for small bag emptying

2. Our solution can achieve automation, intelligent, standardized production

3. Hanrui can provide complete sets of automatic and intelligent production equipment.

No Pollution SS304 2500KG Jumbo Bag Unloading System 0No Pollution SS304 2500KG Jumbo Bag Unloading System 1
