Bulk Materials OEM SS316L Horizontal Loading System

Product Details:
Place of Origin: China
Brand Name: Hanrui
Certification: ISO9001, ISO14001
Model Number: HRU
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: stretch film/plywood
Delivery Time: 4-6 weeks
Payment Terms: T/T, Western Union
Supply Ability: 300 sets / year

Detail Information

Material: SS304, SS316, SS316L, Q235 Applicable Truck: 20ft/40ft/other
Loading Capacity: Depends On Loading Material Accessories: Tubular Chain Conveyor/dump Station Etc.
Filling Efficiency: 98%-100% Existing Case: PP, PVC , PA Etc.
Applicable Material: Powder And Granular Materials Accessories: Screw Conveyor , Slide Gate Valve Etc.
High Light:

316L container loading system


98% horizontal loading system


SS316L Horizontal Loading System

Product Description

Horizontal gravity loading/container loading system for bulk materials


Container loading mainly includes horizontal gravity loading, air transportation loading, screw transportation and belt transportation. According to the market demand, Hanrui Puzer has developed two kinds of automatic loading forms: pneumatic conveying and mechanical conveying. The container automatic loading and unloading system is fast and simple in operation. Employees only need to park the container car at the designated location, use the automatic loading and unloading management system, input the loading amount, and then the container can be loaded automatically. In the process, the loading amount and loading time can be monitored in real time through the operation screen. Compared with the traditional tank car, the container loading efficiency and filling rate are higher, and the dust leakage is zero, which will not cause pollution to the surrounding environment. The automatic loading system has good weight stability, precise loading pressure control, ensuring loading efficiency and avoiding bag bursting risk, effectively improving loading and unloading efficiency, reducing the storage cost of warehouse area and transfer.

technical parameters Model HRU
Unloading Speed depends on material
Air consumption depends on working condition
applicable material good flow ability material
Frame Material Carbon steel, 304,304L / 316L stainless steel
Power & Output 3 phase 380V 50Hz
Accessories screw conveyor, diverter valve , rotary valve etc.
Working condition pneumatic/gravity

It is suitable for the loading of powder and granular materials with a height of more than 20 m in the silo foundation without additional energy, and the filling rate is more than 95%;

Actual case parameters:

(1) Material PTA, 40 foot container, actual loading 27.5t; loading time 15min, filling rate 100%.

(2) Material PP, 40 foot container, actual loading 18t; loading time 35min, filling rate 98%.

(3) Material PA, 40 foot container, actual loading 18t; loading time 40min, filling rate 98%.

Accession Pneumatic conveying and loading

It is suitable for the loading of granular materials with a height of more than 1 m of the silo foundation. There is no special requirement for the parking position of the tank car. It is equipped with an air supply system with a filling rate of 100%;

Actual case parameters:

(4) Material PA, 40 foot container actual loading 20t; loading time 45min, filling rate 98%.

(5) Material PVC, 40 foot container actual loading 18t; loading time 25min, filling rate 100%.


Features of Hanrui's bulk truck loading system :

1. The weight can be controlled stably by the automatic loading system .

2. The loading pressure can be controlled accurately , which guarantees the filling efficiency , meanwhile , it can avoid bag bursting risk .

3. Improve loading efficiency .

4. Can reduce the storage area of warehouse and the cost of storage transfer.


Types of truck loading system

1. Level gravity loading system

 This type of loading system applies to silo over 20M , no additional energy required, the filling efficiency is over 95%.

2.Pneumatic conveying loading system

This type of loading system applies  to granule material loading and the silo foundation is over 1M . No special requirement of container car position. The pneumatic conveying system is integrated. Filling efficiency reaches 100%.

3. Mechnical conveying loading system

This system can contain different combanations: big bag unloading +tubular chain conveying system

                                                                              dump station +tubular chain conveying system

                                                                               big bag unloading +screw conveyor

                                                                               dunmp station +screw conveyor .

Hanrui Puzer is a high-tech enterprisebuilt in 2002 , we are a professional supplier for providing solid bulk material handling solutions, integrated with designing , manufacturing sales and EPC service . Our mission is delicated to provide excellent solutions and services of handling solid bulk material in order to consistently create maximum value for customers.Bulk Materials OEM SS316L Horizontal Loading System 0

Why Choose Us?

  1. We provide OEM/ODM products and services according to international standard and customer requirements. We accept customer label / logo.
  2. We have R&D abilities to enhance product performance and quality according to customer’s demands.
  3. We have nearly 20 years of experience in bulk material area.
  4. We have many certificates to guarantee and ensure product quality and safety, including ISO 9001: CE, ISO14001 etc.
  5. Any questions will be replied within 24 hours.
