Hygroscopic Material SS316L Tubular Chain Conveyor

Product Details:
Place of Origin: China
Brand Name: Hanrui
Certification: CE
Model Number: HTC80-400
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: stretch film
Delivery Time: 4-8 weeks
Payment Terms: T/T, Western Union
Supply Ability: 600sets/year

Detail Information

Material: SS304, SS316, SS316L, Q235 Location: Indoor/outdoor
Horizontal Length: 80M Vertical Length: 60m
Accessories: Rotary Valve,slide Gate Valve Etc. Single Power: Less Than 15KW
High Light:

15KW tubular drag conveyor

,

SS316L Tubular Chain Conveyor

,

60m Tubular Chain Conveyor

Product Description

Tubular Chain scraper conveyor system for hygroscopic material​



Tubular chain conveying solution is applicable for conveying bulk material like powder, small particle and small lump etc. It can be conveyed in horizontal, inclined, and vertical way. It is also applicable for the material conveying in explosion-proof area.

This solution can be designed according to the different material, conveying distance, and downstream or upstream requirements, including the explosion-proof area.



Tube Chian Conveyor Design Data:

Capacity = 300m3/h

Length: horizontal =80m Vertical =60m

Single machine power: =15KW



Main technical parameters for DN100 tubular chain conveyor:

Q(m³/h) 1.25 2.00 2.65 4.00 5.50 7.00 8.75
P(KW) 0.75 1.10 1.50 2.20 3.00 4.00 4.00
V(m/s) 0.06 0.09 0.13 0.19 0.26 0.33 0.42
n(1/min) 3.20 5.40 7.30 11.00 15.00 19.00 4.00



Tubular Conveyor Features:



  •  Provides totally enclosed, dust-free, contamination-free handling,no need dust collector at the discharge.
  •  Requires minimum horsepower and energy consumption.
  • Handles hot, cold, wet, dry, hygroscopic or temperature sensitive materials.
  • Self feeding with most flowable materials.
  • Gentle conveying action minimizes product attrition.
  • May discharge at multiple points in circuit; no special airlocks are required.
  • Operates at a minimum noise level.
  • Easily assembled in the field.
  • Saving cross-section Space,can be installed where other conveyor types cannot.
  • Food grade, polished stainless steel chain for food and pharmaceutical applications in sanitary environments.
  • Wide range of sizes and materials of construction as required.

Solution discription:

The chain, as the drive device, drives the material moving in the closed pipeline.

When conveyed horizontally, the solid material is pushed by disk in the running way. When the internal friction of the material layer is larger than the external friction between the material and pipe wall, the material will move forward via the disks and form stable material flow;

When conveyed vertically, the material is pushed up by the disks, at the same time, the bottom feeding will prevent the upper material from falling down, thus generates horizontal side pressure which increases the internal friction. When the internal friction between the materials is larger than the external friction between the material and pipe wall and its own gravity, the material will move upward via disks and thus forms continuous material flow.

Hygroscopic Material SS316L Tubular Chain Conveyor 0
