Product Details:
|
|
| Place of Origin: | China |
|---|---|
| Brand Name: | Hanrui |
| Certification: | CE |
| Model Number: | HTC80-400 |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 1 set |
| Price: | 5000-50000USD |
| Packaging Details: | stretch film |
| Delivery Time: | 4-8 weeks |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 600sets/year |
|
Detail Information |
|||
| Material: | SS304, SS316, SS316L, Q235 | Capacity: | Less Than 300m³/h |
|---|---|---|---|
| Length: | Less Than 80M (horizontal) | Location: | Indoor Or Outdoor |
| Single Power: | Less Than 15KW | Vertical Length: | 60m |
| High Light: | SS316L tubular drag conveyor,80M Tubular Chain Conveyor,60M Tubular Chain Conveyor |
||
Product Description
Multiple points tubular drag chain conveyor with low noisy discs
The pipe chain transportation solution is suitable for continuous transportation of powder, small granule, small block and other bulk materials. It can be transported horizontally, obliquely and vertically. It can also be used for material transportation in explosion-proof area.
The solution can be designed according to different materials, different conveying distance and different upstream and downstream needs of customers, including the material transportation applied in explosion-proof area.
Necessary information when order:
1. Location: indoor or outdoor
2. Kindly provide the installment position and the conveying distance
3. Capacity(KG/H), and remark the ration conveying or variable conveying
4. Product characteristic: name, size, bulk density, temperature, stickness and other special characteristics
5. Flange standard and flange dimension
6. Please provide reducer motor working voltage, IP grade Ex-proof grade and other automation control requirements
Tube Chian Conveyor Design Data:
Capacity = 300m3/h
Length: horizontal =80m Vertical =60m
Single machine power: =15KW
Main technical parameters for DN100 tubular chain conveyor:
| Q(m³/h) | 1.25 | 2.00 | 2.65 | 4.00 | 5.50 | 7.00 | 8.75 |
| P(KW) | 0.75 | 1.10 | 1.50 | 2.20 | 3.00 | 4.00 | 4.00 |
| V(m/s) | 0.06 | 0.09 | 0.13 | 0.19 | 0.26 | 0.33 | 0.42 |
| n(1/min) | 3.20 | 5.40 | 7.30 | 11.00 | 15.00 | 19.00 | 4.00 |
